Hacking ▍

AirTags · Deep Dive · 16 volumes

AirTags

A deep dive in 16 volumes, starting with a plain-language “Am I being tracked?” walkthrough — then how trackers work, how to use and DIY them, which work on which phone, and how to find a hidden one.

Item trackers ("air tags") end-to-end — the BLE Find My network, UWB, NFC/anti-stalking theory, the tracker varieties, and the counter-surveillance half: detecting hidden tags.

Search every volume:

?

How to search

sten gun
pages with both words
"sten gun"
the words together, as a phrase
sten OR sterling
either one (| works too)
sten -replica
leave out pages that mention “replica”

Without quotes, the last word also matches longer words that start with it (sten finds Stenophylla), and close word forms count (rifle finds rifles). Tick Exact words to match whole words only.

Other words for the same thing are searched too (uniselector also finds stepping switch), ranked below pages with your own words; the results say what else was searched. Quotes or Exact words turn that off.

Whole deep dives are listed first, then the pages inside them. Click a topic under the box to narrow the results.

Tick Photos to search the captions of every photo and diagram; each picture opens where it sits in its volume. The Show row narrows to one kind of result: volumes, deep dives, photos, parts lists, Library documents or downloads.

    Volumes

    1. Vol 0 AirTags Volume 0 — Start Here: Am I Being Tracked? A plain-language, step-by-step walkthrough for finding a hidden AirTag or other item tracker — no technical background and no special gear, just the phone you already have
    2. Vol 1 AirTags Volume 1 — Overview & the Item-Tracker Landscape What item trackers are, the four find-networks, the two halves of this deep dive, where it sits in the hub, the buy/detect decision tree, and depth indices into Vols 2-15
    3. Vol 2 AirTags Volume 2 — Theory I: BLE Advertising & the Find My Crowd-Sourced Network The non-connectable advertising PDU, Apple's 0x004C/0x12 Find My data, the rotating NIST P-224 key chain, finder-side ECIES encryption, owner-side query-and-decrypt, and why a plain MAC scan can never follow the tag
    4. Vol 3 AirTags Volume 3 — Theory II: Ultra-Wideband Precision Finding Apple's U1/U2 silicon, the IEEE 802.15.4z HRP impulse-radio PHY, the channel-5/9 plan at 499.2 MHz, distance from two-way time-of-flight, bearing from multi-antenna angle-of-arrival, the distance-arrow-and-haptics UX, how Samsung SmartTag UWB compares — and why a 6 GHz-ceiling HackRF rules UWB off the bench
    5. Vol 4 AirTags Volume 4 — Theory III: NFC, Lost Mode & the Anti-Stalking / Separated-Beaconing Behavior The passive NDEF tag any phone can read, the found.apple.com / Lost-Mode contact path, the status-byte 'paired vs separated' distinction, the long-lived separated-state key that makes a tag detectable, the audible-chirp and Found-Moving-With-You countermeasures, the detection-delay-by-design rationale, and the Apple+Google DULT framework — the bridge from the tracker half into the detection half
    6. Vol 5 AirTags Volume 5 — AirTag Hardware Teardown The 31.9 mm puck opened: the Nordic nRF52832 BLE SoC and its NFCT peripheral, the Apple U1 UWB responder, the NXP NT3H2111 NTAG-I²C-plus front-end (Type-2 / 14443-A, pinned), the voice-coil speaker that doubles as the battery interlock, the CR2032 power tree and its one-year current budget, and how three radios and three antennas coexist in an 8 mm coin
    7. Vol 6 AirTags Volume 6 — How to Use Them: The Full AirTag Lifecycle One-tap pairing and Apple-ID binding; the Find My Items tab; Precision Finding (UWB) walkthrough; Lost Mode and the NFC contact path; sharing up to five people (iOS 17+); CR2032 battery replacement; and the honest account of Apple-ecosystem lock-in — this volume is the operational manual the theory volumes (Vols 2–4) built toward
    8. Vol 7 AirTags Volume 7 — Varieties I: Apple AirTag & Samsung SmartTag/SmartTag2 The two ecosystem-native UWB trackers side by side: AirTag specification recap, the three Samsung SmartTag generations (BLE-only baseline → UWB-augmented SmartTag+ → IP67 SmartTag2 with ~700-day battery), SmartThings Find vs Find My at network scale, head-to-head spec and feature matrices, the Galaxy-device registration lock, and the programmable-button feature the AirTag never had
    9. Vol 8 AirTags Volume 8 — Varieties II: Tile, Chipolo, Pebblebee & Cross-Network Tags The BLE-only and 'Find My or Google' trackers: Tile's own-network cross-platform line (Mate/Pro/Slim/Sticker, Life360, Amazon Sidewalk, no UWB); Chipolo's one-network-per-SKU architecture (ONE Spot / CARD Spot = Find My; POINT / CARD POINT = Google); Pebblebee's rechargeable variants; the consumer-confusion trap at the heart of this category; and the complete cross-network variety matrix
    10. Vol 9 AirTags Volume 9 — Which Works on Which Phone: The Network Map The definitive Android-vs-iPhone matrix: the four verbs (register / locate / be-found-by / detect) defined with engineering precision, then applied across every finding network and every OS — Apple Find My, Samsung SmartThings Find, Google Find My Device, and Tile; the key asymmetries (Android can detect but not own an AirTag; iPhone cannot register a SmartTag; Tile is the only register-on-either-OS option); and the Apple+Google DULT cross-platform detection cooperation that lets each OS alert on the other ecosystem's trackers
    11. Vol 10 AirTags Volume 10 — DIY: OpenHaystack & Macless-Haystack Turning a $5 ESP32 or an nRF52 into a Find My beacon: the original macOS-app-plus-Mail-plugin architecture, why the anisette server replaced the Mac, the P-224 key-gen → flash → advertise → fetch → decrypt pipeline that reuses Vol 2's payload byte-for-byte, a build BoM with the honest battery-life math, and the posture envelope for riding Apple's network without an MFi certificate
    12. Vol 11 AirTags Volume 11 — Detection Devices for Hidden/Unwanted Tags The complete detection landscape: iOS and Android OS-native alerts, Tracker Detect (Android, manual scan), AirGuard (TU Darmstadt), commercial BLE scanners and RF bug-sweepers, the Apple+Google DULT draft spec, and an honest can/cannot matrix of what each tool actually sees — with the false-sense-of-security caveat front and center
    13. Vol 12 AirTags Volume 12 — DIY Detection & Finding The engineer-on-the-bench counter-surveillance toolkit: nRF Connect, bluetoothctl, btmon and the legacy hcitool path, an nRF52840 sniffer feeding Wireshark, the FF 4C 00 12 separated-state signature to match on, the key-rotation problem and why you correlate persistence + RSSI within one sweep session instead of across rotations, a bleak RSSI-walk logger, the NFC serial read, and the reproducible sweep-your-own-car/bag/room decision tree
    14. Vol 13 AirTags Volume 13 — Add-ons to Your Existing Hack Tools Gear Turning the bench you already own into a tracker-sweep kit: the Flipper Zero BLE stack and its community scanner FAPs, ESP32 Marauder on the AWOK Dual Touch V3 (and why AirTag Detect lives in Ghost ESP / Bruce, not mainline), the Ruckus Game Over multitool, the Nyan Box as the counter-surveillance sibling, the nRF52840 dongle as the clean sniffer path, and the HackRF One UWB-band question answered correctly — a 6 GHz ceiling means it cannot receive UWB at all
    15. Vol 14 AirTags Volume 14 — Operational Posture, Legal & Ethics The make-vs-find line, lawful and unlawful uses, the consent bright line, regional law pointers, data-handling rules for detection sweeps, DIY-beacon ToS boundaries, and the presence-not-proof caveat — the ethical and legal capstone of the series
    16. Vol 15 AirTags Volume 15 — Cheatsheet: Laminate-Ready Field Card Detect / read / DIY / gear / network map / legal — one-page synthesis of the fifteen-volume series
